Spring Rates Chart


Yokomo (Pro shock spring long type with color marking at the bottom)
  • Black - 258 gF/mm
  • Blue - 264 gF/mm
  • Yellow - 280 gF/mm
  • Pink - 290 gF/mm
  • Green - 303 gF/mm
  • Orange - 330 gF/mm

HPI Racing (Color marking at the bottom of the spring)
  • Blue - 273 gF/mm
  • Silver - 302 gF/mm
  • Pink - 320 gF/mm
  • Gold - 340 gF/mm
  • White - 363 gF/mm
  • Yellow - 388 gF/mm
  • Red - 400 gF/mm

Hara Spring V.1 (Color marking at the bottom of the spring)
  • Yellow - 230gF/mm
  • White - 250 gF/mm
  • Black 270 gF/mm
  • Purple - 290 gF/mm
  • Red - 310 gF/mm

Top Racing (Spring Rate engrave on the spring)
  • Gamma 393 gF/mm
  • Gamma 367 gF/mm
  • Gamma 344 gF/mm
  • Gamma 324 gF/mm
  • Gamma 306 gF/mm
  • Gamma 289 gF/mm
  • Alpha 626 gF/mm
  • Alpha 591 gF/mm
  • Alpha 560 gF/mm
  • Alpha 532 gF/mm
  • Alpha 507 gF/mm
  • Beta 347 gF/mm
  • Beta 325 gF/mm
  • Beta 306 gF/mm
  • Beta 294 gF/mm
  • Beta 274 gF/mm
*Gamma Spring is design for rubber asphalt racing
*Alpha & Beta spring is design for carpet and foam tire racing
